Description

3.5” 24W Double Regressed Gimbal Downlight

Our Recessed family has grown with a new range of adjustable downlights. The effortless design and high functionality of these fixtures are sure to make a welcome addition in any room. Transform any space into a well-lit, stylish haven with our selection of adjustable downlights. The sleek design and impressive functionality of these fixtures make them a must-have for any room in your home. Say goodbye to dull and uninviting lighting, and hello to a brighter, more inviting atmosphere!

• Includes a junction box with integrated dimmable driver
• Can be daisy chained
• Superior LED performance and lifespan
• 30° tilting, 360° rotation
• Minimal heat emission
• Aluminum construction
• Switch-selectable CCT: 2700K/3000K/3500 K/4000 K/5000 K
• Low profile
• 40° beam spread
• IC certification (suitable for direct contact with insulation)
• Air-tight certified as per ASTM E283-04
• Suitable for wet locations
• Ideal operating temperature: -20° to 40° C
• 5-year warranty

Fixture Type	Dual Regressed Gimbal Downlight
Finish	White, Black
Wattage	24W
Lumen Output	1740L
CCT (Kelvin)	27K-50K
Temperature	Selectable
Indoor or Outdoor Fixture	Wet Location Rated

Spec Sheet

Spec Sheet

Installation Instructions

Catalog Sheet

Info

Technology	LED
Wattage	24W
Lumen	1740L
CCT (Kelvin)	27K-50K
Color Temp.	Selectable
CRI	>90
Voltage	120V
Rated Hours	50000
Dimmable	Yes-Dimmable See Spec Sheet
Tilt/Rotation	30° tilting, 360° rotation
Beam Spread	40°
Weight (lb.)	1.00

Width (in.)	7-11/16″ x 4-1/4″
Cutout (in.)	7-1/8″ x 3-1/2″
Height (in.)	2-7/16″”

Additional Info

SKU	GBR35-CC-DUO
Safety Listing	UL Listed, ETL Listed
Location Rating	Wet Location
Energy Star	Yes
Warranty	5 Years
