Dual-Lite DYNHL12I-4X-FP Dynamo High Lumen LED Emergency Light with Self Diagnostics, 32W (2 x 16W LED Lamps), Food Processing Rated, Gray

Description

Features• High lumen, high mounting height• Up to 168′ multi-unit spacing• 90-minute full lumen output• Self-test/self-diagnostics standard• Wet and NEMA 4X application• Food processing option• Remote laser tester option• Long-life lithium iron phosphate battery• CEC T20 compliant• Matching remote headsApplication• Highly versatile superior lumen output, industrial application emergency lighting unit, designed to provide a minimum of 90 minutes illumination when primary power is lost• Includes microcontroller based 3-stage charger and Lithium Iron Phosphate (LiFePO4) battery• Specifically designed for demanding environments, high reliability operation in industrial settings such as high ceiling, wet location, hose-down, food processing, food storage, production facilities, chemical plants, and wastewater treatmentConstruction• Flame-rated, UV stable thermoplastic housing which is fully gasketed and corrosion resistant with a gray finish• The DYN series housing, covers, remote housing and shield are made of polycarbonate• Lampheads are made of die-cast aluminum for thermal dissipation• LED lenses are made of polycarbonateInstallation• Includes a universal mounting plate which facilitates mounting to a truss or I-beam, pole, column, or wall• Special bracket included to ensure positive pole gripping when using bands• In wet or NEMA 4X applications, use UL listed watertight conduit fittings that meet the requirements of the UL 514B Standard for Conduit Tubing and Cable Fittings when using knockouts on the side or top of unit• The DYN Series accepts 120 through 277VAC input at 50 or 60Hz• Not designed for self-diagnostic operation at 220-240VAC input• Universal mounting plate made of painted stamped steelIllumination• Each lamphead provides 1,106 lumens for total lumen output of 2,212 lumens• Provides a bright and uniform illumination and is specifically designed for higher mounting heights above 9’• Coverage produced by two 8 watt (each) sealed aluminum lampheads using 6 high power LEDs each• LEDs housed in a specially designed, heat dissipating, fully adjustable lamphead which can be locked into position• Designed for full lumen output across the entire safety code required 90 minutes of operation to ensure maximum visibility for emergency path of egress
