Dual-Lite SEMRDRWE Die-Cast Aluminum Master/Remote Exit Sign Set with Emergency Operation, Double Face, White with Red Letters

Description

Features• 5-minute installation• High-strength cast aluminum• Long-life LED lamps• 120/277 VAC operation, 60 Hz operationApplication• The Sempra MR Series are a set of compact, low-profile Master/Remote exit sign featuring cast aluminum construction• It allows for easy installation and has energy saving, long-life LED lampsConstruction• The Sempra MR Series housing, exit face(s) and matching canopy are constructed of high strength cast aluminum• The diffuser has a frequency-matched silk screened coating that provides optimized LED light output• The unit comes with 6″ letters with a 3/4″ stroke and chevron directional arrowsInstallation• The master and remote unit signs mount to 3 1/2″, 4″ octagon or 4″ square outlet boxes and standard plaster rings• Exit signs housings are provided with knockout pattern for mounting to standard outlet boxes• Ceiling and end installations are available for the master unit only and mounting canopy is provided• The canopy mounts to outlet boxes by means of a universal mounting plate which is supplied• Exit mounts to canopy bracket• Wiring for the master exits are a pre-stripped AC input pigtail leads and wiring for remote exits are an interconnecting wiring that consists of three- 18 gauge (min.) AC conductors which are supplied by installerIllumination• The master unit comes with 4 high-output LEDs and the remote unit come with 6 high-output LEDs• LEDs have an excess of 20 year life• Brightness index and illumination uniformity both exceed UL requirementsCompliances• UL 924 Listed• NFPA 101 Life Safety Code• CEC T20 Compliant
