Description

Duplex Combo Decorator Switch Over Switch

Eaton commercial grade combination switch, auto-ground, Decorator, #14 – #12 AWG, 15A, residential, comm, 120/277V, back and side wiring, Rocker, Maintain closure, Screw, Brass, white, -20°-60°C, (2) 1-pole, duplex, thermoplastic, polycarbonate, PVC

• 120/277V/AC rating is ideal for incandescent or fluorescent lighting fixtures
• Thermoplastic rocker, top and back body are virtually unbreakable to deliver years of durable performance
• Ultrasonic welding and integrated construction of the strap and body provide superior ground integrity even under heavy use
• Durable, injection molded housings and PVC resin comply with UL94 V0 flammability ratings
• Automatic grounding system eliminates the need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where a jumper is used
• Steel mounting strap is zinc-plated for added corrosion resistance
• Back wire clamps on side terminals provide for easy installation of #12 and #14 wire
• Terminal screws are backed out and ready for wiring to enhance ease of installation
• Break-off provision on switches for wiring both devices on the same circuit or on separate circuits
