K4023C Button 208-277 Volt Thermal Photocontrol

K4023C Button 208-277 Volt Thermal Photocontrol

Original price was: $18.70.Current price is: $4.97.

SKU: ddnihnkr29143 Category: Tag:

Description

These photocontrols install within lighting fixtures, post lamps, or in-wall boxes to provide dusk-to-dawn ON/OFF control of outdoor lighting.

This K4023C 208-277 Volt Thermal Photocontrol with a mechanical bimetal switch and Cadmium Sulfide photocell offers a compact size that fits into standard outlet boxes, post lamps, wall packs, and other lighting fixtures. It also has a delay feature that prevents unwanted OFF switching and includes a 3/8″-18 NPSM 3/4″ long stem with a locking nut and washer gasket.

Manufacturer Intermatic
MPN K4023C
SKU K4023C
UPC 078275029576
Application Compatibilities Fluorescent; HID; Incandescent
Input Voltage 208-277 VAC
Frequency 50/60Hz
Sensor Time Delay 30 Seconds to 90 Seconds
Activation On 1 to 5FC
Activation Off 3 to 15FC
Housing Polycarbonate
Magnetic Ballast Range 8.3 A
Tungsten Range 15 A
Rated Life 5 Years
Operating Temperature -40°C to 70°C
Dimensions 1-13/16″ H x 15/16″ W x 13/16″ Depth
Wire Lead Length 9 Inches
Maximum Wire Size #18 AWG
Certifications UL, Title 20
Environment Outdoor
Warranty 2 Year Limited
