K4123C Stem Mount 208-277 Volt Thermal Photocontrol

K4123C Stem Mount 208-277 Volt Thermal Photocontrol

Original price was: $29.56.Current price is: $7.94.

SKU: utcjqnnm36518 Category: Tag:

Description

These photocontrols install on standard outdoor light fixtures and electrical boxes with 1/2″-14 NPSM thread or 7/8″ knock-out holes for dusk-to-dawn ON/OFF control of outdoor lighting.

The K4123C Stem Mount 208-277 Volt Thermal Photocontrol is designed to provide dependable performance with its reliable mechanical bimetal switch and Cadmium Sulfide photocell. The delay feature prevents OFF switching while the gray plastic housing provides protection from water and dust. Installation is made easy with 9 inches leads, a washer gasket, and a locking nut included.

Manufacturer Intermatic
MPN K4123C
SKU K4123C
UPC 078275029590
Application Compatibilities Fluorescent; HID; Incandescent
Input Voltage 208-277 VAC
Frequency 50/60Hz
Sensor Time Delay 30 Seconds to 90 Seconds
Activation On 1 to 5FC
Activation Off 3 to 15FC
Housing Polycarbonate
Magnetic Ballast Range 8.3 A
Tungsten Range 15 A
Rated Life 5 Years
Operating Temperature -40°C to 70°C
Dimensions 3″ H x 1-9/16″ W x 1-9/16″ Depth
Wire Lead Length 9 Inches
Maximum Wire Size #18 AWG
Certifications UL, Title 20
Environment Outdoor
Warranty 2 Year Limited
