Description

20W 4″ Surface/Pendant Mount Selectable CCT

Please call for lead times before placing order.

This 4-inch CD34 cylinder is dimmable and ideal for surface or pendant mounting in indoor applications. This fixture provides superior downward facing light with a clear lens and field adjustable color temperatures from 27K-50K

Click Here for Adjustable Stem Mount

• Aluminum extrusion housing and die-casting covers
• Field adjustable color temperatures between 27K-50K
• Smooth, diffused downward light output
• Pendant mount accessory sold separately
• 0-10V dimming
• 90 CRI provides high color rendering

Spec Sheets

Spec Sheet

Installation Instructions

Info

Product Type	Economy Cylinder
Wattage	20W
Lumen	1500
Color Temp.	Field Adjustable (27K-50K)
CRI	90
L70 Lifespan	100,000
Material	Metal
Style	Smooth
Beam Angle	50°
LED	LED array provides a uniform source with high efficiency and no pixilation
Lens	Regressed lens constructed from impact resistant polycarbonate. Convex lens gives the optic a similar lamp-like appearance. Provides smooth and diffuse light distribution
Mounting	Surface Mount. Pendant mount accessories available sold separately
Housing Material	Cylinder aluminum extrusion/cover aluminum die casting

Additional Info

Compliance Safety Listing UL Listed Environment Rating Suitable for use in dry, damp, and wet environments California Energy Commission (CEC) Status: Not lawful for sale in California Energy Star ID White- CD1011 Black- CD1010 Bronze- CD1011 Energy Star Compliant This product is ENERGY STAR® Version 2.2 Certified. IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80 FCC Complies with Part 15 of the FCC Rules

Electrical THD ≤20% Driver Constant Current, Non-Isolated Driver, 50/60 Hz, 120-277V, 120V: 0.18A, 208V: 0.11A, 240V: 0.09A, 277V: 0.08A Dimming Driver Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 5%. Input Voltage 120-277V Operating Frequency 60Hz Dimming Yes, 0-10V continuous dimming
